Pendant Cable Description
Pendant cable features two galvanized steel wire ropes embedded on opposite sides of its sheath, allowing for a maximum suspension height of 80 meters. Each steel core has a tensile strength of 2100 Newtons, enabling it to withstand high mechanical stress, torsion, torque, and tension. Its applications encompass cranes, mining and construction equipment, and conveying systems.
Pendant Cable Construction
- Conductor
- Class 6 fine flexible stranded plain Copper
- Insulation
- XLPE (Cross linked polyethylene compound)
- Lay Up
- Cores laid up in concentric layers
- Tape
- Textile
- Suspension Support
- Galvanized steel wire ropes at both sides
- Outer Sheath
- PVC (Polyvinyl chloride)
Pendant Cable Characteristics
- Voltage Rating (Uo/U)
- 300/500V
- Temperature Rating
- Fixed: -40°C to + 70°C
- Mobile: -25°C to +70°C
- Minimum Bending Radius
- Fixed: 10 x Overall Diameter
- Mobile: 20 x Overall Diameter
- Maximum Tensile Load
- 15 N/mm²
- Maximum Suspended Height
- 80 meters
- Pulling Force
- 2100 N for each steel core
Pendant Cable Specifications
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm | NOMINAL WEIGHT kg/km |
|
|---|---|---|---|---|
| Minimum | Maximum | |||
| 5 | 1.5 | 10 | 20 | 210 |
| 6 | 1.5 | 10.3 | 19 | 255 |
| 8 | 1.5 | 12.5 | 22 | 300 |
| 10 | 1.5 | 12.4 | 21 | 330 |
| 12 | 1.5 | 13 | 23 | 350 |
| 14 | 1.5 | 13.4 | 22 | 405 |
| 16 | 1.5 | 15.5 | 25.5 | 440 |
| 20 | 1.5 | 16.5 | 27.5 | 525 |
| 24 | 1.5 | 19.9 | 29.5 | 575 |
