Pump Cable 300 Description
Pump Cable 300 has an AD8 waterproof rating and can withstand long-term immersion in water. It can be installed in both freshwater and seawater and is suitable for use in various industries, including agriculture, mining, and food processing.
300 Pump Cable features a flat construction and is available in three- and four-core configurations with green and yellow core colors. Its rugged ethylene propylene rubber (EPR) insulation is temperature-resistant down to -40°C. The neoprene jacket provides a flame-retardant, UV-resistant, and ozone-resistant barrier.
Pump Cable 300 Construction
- Conductor
- Class 5 Tinned Copper
- Insulation
- EPR (Ethylene Propylene Rubber) Compound – 3GI3 Quality
- Sheath
- Water Resistant Rubber Compound – EM2 Quality
Pump Cable 300 Characteristics
- Voltage Rating Uo/U
- 0.6/1kV
- Maximum AC Voltage
- 0.7/1.2kV, 1.8kV DC
- Temperature Rating
- Fixed: -40ºC to 90ºC
- Flexed: -25ºC to +90ºC
- Maximum short circuit temperature: 250ºC
- Minimum Bending Radius
- Height < 12 mm: 3 x H
- Height > 12 mm: 4 x H
Pump Cable 300 Specifications
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL DIAMETER OF CONDUCTOR mm | HEIGHT mm | WIDTH mm | NOMINAL WEIGHT kg/km | MAXIMUM TENSILE LOAD N | ||
|---|---|---|---|---|---|---|---|---|
| Minimum | Maximum | Minimum | Maximum | |||||
| 3 | 4 | 2.4 | 7 | 8 | 15.5 | 16.5 | 260 | 180 |
| 3 | 6 | 2.9 | 7.5 | 8.5 | 17.5 | 18.5 | 330 | 270 |
| 3 | 10 | 3.8 | 10.3 | 11 | 23.1 | 24.1 | 550 | 450 |
| 3 | 16 | 4.9 | 12.2 | 13.2 | 28 | 29.5 | 820 | 720 |
| 3 | 25 | 6.1 | 14.2 | 15.2 | 33 | 34.5 | 1180 | 1125 |
| 3 | 35 | 7.2 | 16 | 17.5 | 37 | 38.7 | 1560 | 1575 |
| 3 | 50 | 8.9 | 18.5 | 20 | 44.1 | 45.8 | 2190 | 2250 |
| 3 | 70 | 10.6 | 20.5 | 22 | 50.5 | 52.5 | 2890 | 3150 |
| 3 | 95 | 12.3 | 23.1 | 23.9 | 57.1 | 57.9 | 3610 | 4275 |
| 3 | 120 | 14.2 | 25.1 | 25.9 | 62.1 | 62.9 | 4420 | 5400 |
| 3 | 150 | 15.5 | 26.8 | 27.6 | 67.2 | 68 | 5370 | 6750 |
| 3 | 185 | 17 | 28.6 | 29.4 | 72.6 | 73.4 | 6440 | 8325 |
| 4 | 4 | 2.4 | 8 | 9 | 23 | 24 | 400 | 240 |
| 4 | 6 | 2.9 | 8.5 | 9.5 | 24.5 | 25.5 | 490 | 360 |
| 4 | 10 | 3.8 | 10 | 11 | 29.5 | 30.5 | 710 | 600 |
| 4 | 16 | 4.9 | 12 | 13 | 34.5 | 35.5 | 1040 | 960 |
| 4 | 25 | 6.1 | 15.8 | 17.2 | 42.l | 43.5 | 1660 | 1500 |
| 4 | 35 | 7.2 | 18.6 | 19.4 | 48.6 | 49.8 | 2190 | 2100 |
| 4 | 50 | 8.9 | 19.4 | 20.2 | 56.8 | 57.6 | 2880 | 3000 |
| 4 | 70 | 10.6 | 24 | 24.8 | 65.4 | 66.6 | 4060 | 4200 |
| 4 | 95 | 12.3 | 25.6 | 26.4 | 73 | 74.2 | 5050 | 5700 |
| 4 | 120 | 14.2 | 24.3 | 25.l | 73.8 | 75 | 5580 | 7200 |
