BS5308 / PAS5308 Part 1 Type 2 Cable Description
The cable typically consists of copper conductors, XLPE insulation, twisted pairs or tris, overall shield (usually Al/Polyester tape), PE bedding, steel wire armour and LSHF (Low Smoke Zero Halogen) jacket. The Al/PET tape can be laid either overall or separately (CAM or ICAM), depending on the degree of shielding required.
These cables are used to transmit a variety of signals from sensors and transducers to control systems, including analog, data, and voice. They are commonly used in the petroleum and petrochemical industries and other interconnect applications that require control and monitoring.
Despite having been withdrawn over 10 years ago to be replaced by the harmonised European standard EN 50288-7, the BS5308 and the PAS 5308 cables are still commonly specified around the world.
BS5308 / PAS5308 Part 1 Type 2 Cable Construction
| BS5308 Part 1 Type 2 CAM / ICAM SWA Silicone LSZH Cable | BS5308 Part 1 Type 2 CAM / ICAM SWA PE PVC Cable | BS5308 Part 1 Type 2 CAM / ICAM SWA XLPE LSZH Cable | BS5308 Part 1 Type 2 CAM / ICAM Mica SWA XLPE LSZH Cable | |
|---|---|---|---|---|
| VOLTAGE | 300/500V | |||
| CONDUCTOR | Class 1 Solid Copper Class 2 Stranded Copper Class 5 Flexible Stranded Copper |
|||
| INSULATION | Silicone Rubber Ceramic Type | PE (Polyethylene) | XLPE (Cross-Linked Polyethylene) | MICA Tape + XLPE (Cross-Linked Polyethylene) |
| BINDER TAPE | PET (Polyester Tape) | |||
| SCREEN | CAM: Al/PET (Aluminium/Polyester Tape) Collective Screen ICAM: Al/PET (Aluminium/Polyester Tape) Individual and Collective Screen |
|||
| DRAIN WIRE | Tinned Copper | |||
| BEDDING | - | PE (Polyethylene) | - | |
| INNER SHEATH | LSZH (Low Smoke Zero Halogen) | - | LSZH (Low Smoke Zero Halogen) | |
| ARMOUR | SWA (Galvanised Steel Wire) | |||
| OUTER SHEATH | LSZH (Low Smoke Zero Halogen) | PVC (Polyvinyl Chloride) | LSZH (Low Smoke Zero Halogen) | |
BS5308 / PAS5308 Part 1 Type 2 Cable Characteristics
-
- Voltage Rating Uo/U
- 300/500V
- Operating Temperature
- Fixed: -40ºC to +80ºC
- Flexed: 0ºC to +50ºC
- Minimum Bending Radius
- Fixed: 12 x overall diameter
- BS5308 Part 1 Type 2 CAM SWA PE PVC Cable
- BS5308 Part 1 Type 2 ICAM SWA PE PVC Cable
- BS5308 Part 1 Type 2 CAM SWA XLPE LSZH Cable
- BS5308 Part 1 Type 2 ICAM SWA XLPE LSZH Cable
- BS5308 Part 1 Type 2 CAM SWA Silicone LSZH Cable
- BS5308 Part 1 Type 2 ICAM SWA Silicone LSZH Cable
- BS5308 Part 1 Type 2 CAM Mica SWA XLPE LSZH Cable
- BS5308 Part 1 Type 2 ICAM Mica SWA XLPE LSZH Cable
| NO. OF PAIRS/TRIPLE | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm |
|---|---|---|
| 1P | 0.5 | 11.4 |
| 1P | 0.75 | 11.8 |
| 1P | 1 | 11.8 |
| 1P | 1.5 | 12.9 |
| 1P | 2.5 | 13.7 |
| 1T | 0.5 | 11.7 |
| 1T | 0.75 | 12.1 |
| 1T | 1 | 12.3 |
| 1T | 1.5 | 13.5 |
| 1T | 2.5 | 14.3 |
| 2P(Q) | 0.5 | 12.3 |
| 2P(Q) | 0.75 | 13 |
| 2P(Q) | 1 | 13 |
| 2P(Q) | 1.5 | 14.3 |
| 2P(Q) | 2.5 | 15.3 |
| 5P | 0.5 | 17.9 |
| 5P | 0.75 | 19.3 |
| 5P | 1 | 19.7 |
| 5P | 1.5 | 22.1 |
| 5P | 2.5 | 24.1 |
| 10P | 0.5 | 22.9 |
| 10P | 0.75 | 25.5 |
| 10P | 1 | 24.3 |
| 10P | 1.5 | 28.4 |
| 10P | 2.5 | 32.1 |
| 15P | 0.5 | 26.4 |
| 15P | 0.75 | 28.7 |
| 15P | 1 | 28.1 |
| 15P | 1.5 | 32.2 |
| 15P | 2.5 | 36.4 |
| 20P | 0.5 | 29.1 |
| 20P | 0.75 | 31.6 |
| 20P | 1 | 31.2 |
| 20P | 1.5 | 35.7 |
| 20P | 2.5 | 41 |
| NO. OF PAIRS | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm |
|---|---|---|
| 2P | 0.5 | 15.3 |
| 2P | 0.75 | 16 |
| 2P | 1 | 15.9 |
| 2P | 1.5 | 18.6 |
| 2P | 2.5 | 20 |
| 3P | 0.5 | 16.4 |
| 3P | 0.75 | 17.1 |
| 3P | 1 | 17 |
| 3P | 1.5 | 19.7 |
| 3P | 2.5 | 21.1 |
| 5P | 0.5 | 19.1 |
| 5P | 0.75 | 20 |
| 5P | 1 | 20 |
| 5P | 1.5 | 22.5 |
| 5P | 2.5 | 25.5 |
| 10P | 0.5 | 25.6 |
| 10P | 0.75 | 27 |
| 10P | 1 | 27 |
| 10P | 1.5 | 30.7 |
| 10P | 2.5 | 33.9 |
| 15P | 0.5 | 28.7 |
| 15P | 0.75 | 30.6 |
| 15P | 1 | 30.5 |
| 15P | 1.5 | 34.6 |
| 15P | 2.5 | 39.3 |
| 20P | 0.5 | 31.6 |
| 20P | 0.75 | 33.8 |
| 20P | 1 | 33.7 |
| 20P | 1.5 | 39.3 |
| 20P | 2.5 | 43.7 |
| 30P | 0.5 | 36.4 |
| 30P | 0.75 | 39.7 |
| 30P | 1 | 39.6 |
| 30P | 1.5 | 45.2 |
| 30P | 2.5 | 51.6 |
| NO. OF PAIRS/TRIPLE | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm |
|---|---|---|
| 1P | 0.5 | 11.4 |
| 1P | 0.75 | 11.8 |
| 1P | 1 | 11.8 |
| 1P | 1.5 | 12.9 |
| 1P | 2.5 | 13.7 |
| 1T | 0.5 | 11.7 |
| 1T | 0.75 | 12.1 |
| 1T | 1 | 12.3 |
| 1T | 1.5 | 13.5 |
| 1T | 2.5 | 14.3 |
| 2P(Q) | 0.5 | 12.3 |
| 2P (Q) | 0.75 | 13 |
| 2P (Q) | 1 | 13 |
| 2P (Q) | 1.5 | 14.3 |
| 2P (Q) | 2.5 | 15.3 |
| 5P | 0.5 | 17.9 |
| 5P | 1 | 19.7 |
| 5P | 1.5 | 22.1 |
| 5P | 2.5 | 24.1 |
| 5P | 0.75 | 19.3 |
| 10P | 0.5 | 22.9 |
| 10P | 1 | 24.3 |
| 10P | 1.5 | 28.4 |
| 10P | 2.5 | 32.1 |
| 10P | 0.75 | 25.5 |
| 15P | 0.5 | 26.4 |
| 15P | 1 | 28.1 |
| 15P | 1.5 | 32.2 |
| 15P | 2.5 | 36.4 |
| 15P | 0.75 | 28.7 |
| 20P | 0.5 | 29.1 |
| 20P | 1 | 31.2 |
| 20P | 1.5 | 35.7 |
| 20P | 2.5 | 41 |
| 20P | 0.75 | 31.6 |
| NO. OF PAIRS | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm | NOMINAL WEIGHT kg/km |
|---|---|---|---|
| 2P | 0.5 | 15.3 | 316 |
| 2P | 0.75 | 16 | 349 |
| 2P | 1 | 15.9 | 361 |
| 2P | 1.5 | 18.6 | 431 |
| 2P | 2.5 | 20 | 542 |
| 3P | 0.5 | 16.4 | 352 |
| 3P | 0.75 | 17.1 | 393 |
| 3P | 1 | 17 | 411 |
| 3P | 1.5 | 19.7 | 526 |
| 3P | 2.5 | 21.1 | 601 |
| 5P | 0.5 | 19.1 | 454 |
| 5P | 0.75 | 20 | 544 |
| 5P | 1 | 20 | 575 |
| 5P | 1.5 | 22.5 | 802 |
| 5P | 2.5 | 25.5 | 978 |
| 10P | 0.5 | 25.6 | 844 |
| 10P | 0.75 | 27 | 984 |
| 10P | 1 | 27 | 1044 |
| 10P | 1.5 | 30.7 | 1474 |
| 10P | 2.5 | 33.9 | 1813 |
| 15P | 0.5 | 28.7 | 1065 |
| 15P | 0.75 | 30.6 | 1428 |
| 15P | 1 | 30.5 | 1515 |
| 15P | 1.5 | 34.6 | 1857 |
| 15P | 2.5 | 39.3 | 2536 |
| 20P | 0.5 | 31.6 | 1468 |
| 20P | 0.75 | 33.8 | 1695 |
| 20P | 1 | 33.7 | 1812 |
| 20P | 1.5 | 39.3 | 2450 |
| 20P | 2.5 | 43.7 | 3043 |
| 30P | 0.5 | 36.4 | 1862 |
| 30P | 0.75 | 39.7 | 2382 |
| 30P | 1 | 39.6 | 2558 |
| 30P | 1.5 | 45.2 | 3197 |
| 30P | 2.5 | 51.6 | 4032 |
| NO. OF PAIRS/TRIPLE | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm |
|---|---|---|
| 1P | 0.5 | 10.9 |
| 1P | 1 | 11.3 |
| 1P | 1.5 | 12.3 |
| 1P | 2.5 | 13.3 |
| 1P | 0.75 | 11.4 |
| 1T | 0.5 | 11.3 |
| 1T | 1 | 11.7 |
| 1T | 1.5 | 13 |
| 1T | 2.5 | 13.8 |
| 1T | 0.75 | 11.8 |
| 2P(Q) | 0.5 | 11.8 |
| 2P (Q) | 1 | 12.3 |
| 2P (Q) | 1.5 | 13.7 |
| 2P (Q) | 2.5 | 14.7 |
| 2P (Q) | 0.75 | 12.6 |
| 5P | 0.5 | 17.2 |
| 5P | 1 | 18.1 |
| 5P | 1.5 | 21.1 |
| 5P | 2.5 | 23.2 |
| 5P | 0.75 | 18.3 |
| 10P | 0.5 | 23.2 |
| 10P | 1 | 25.9 |
| 10P | 1.5 | 29.3 |
| 10P | 2.5 | 31.8 |
| 10P | 0.75 | 26.2 |
| 15P | 0.5 | 27.2 |
| 15P | 1 | 28.9 |
| 15P | 1.5 | 33.6 |
| 15P | 2.5 | 36.8 |
| 15P | 0.75 | 29.2 |
| 20P | 0.5 | 29.9 |
| 20P | 1 | 31.5 |
| 20P | 1.5 | 37 |
| 20P | 2.5 | 40.9 |
| 20P | 0.75 | 33 |
| NO. OF PAIRS/TRIPLE | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm |
|---|---|---|
| 2P | 0.5 | 14.6 |
| 2P | 1 | 15.4 |
| 2P | 1.5 | 17.7 |
| 2P | 2.5 | 19.9 |
| 2P | 0.75 | 15.8 |
| 3P | 0.5 | 15.4 |
| 3P | 1 | 16.7 |
| 3P | 1.5 | 18.5 |
| 3P | 2.5 | 20.8 |
| 3P | 0.75 | 16.9 |
| 5P | 0.5 | 18.2 |
| 5P | 1 | 19.9 |
| 5P | 1.5 | 22.6 |
| 5P | 2.5 | 25.9 |
| 5P | 0.75 | 20.1 |
| 10P | 0.5 | 26 |
| 10P | 1 | 27.4 |
| 10P | 1.5 | 31 |
| 10P | 2.5 | 34.9 |
| 10P | 0.75 | 27.7 |
| 15P | 0.5 | 29.1 |
| 15P | 1 | 30.6 |
| 15P | 1.5 | 35.8 |
| 15P | 2.5 | 39.2 |
| 15P | 0.75 | 31 |
| 20P | 0.5 | 31.8 |
| 20P | 1 | 34.8 |
| 20P | 1.5 | 39.7 |
| 20P | 2.5 | 43.4 |
| 20P | 0.75 | 35.2 |
| 30P | 0.5 | 37.2 |
| 30P | 1 | 39.7 |
| 30P | 1.5 | 45.2 |
| 30P | 2.5 | 50.6 |
| 30P | 0.75 | 40.3 |
| NO. OF PAIRS/TRIPLE | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm |
|---|---|---|
| 1P | 0.5 | 11.5 |
| 1P | 0.75 | 12 |
| 1P | 1 | 11.9 |
| 1P | 1.5 | 13.1 |
| 1P | 2.5 | 13.9 |
| 1T | 0.5 | 11.9 |
| 1T | 0.75 | 12.6 |
| 1T | 1 | 12.3 |
| 1T | 1.5 | 13.6 |
| 1T | 2.5 | 14.5 |
| 2P(Q) | 0.5 | 12.8 |
| 2P(Q) | 0.75 | 13.4 |
| 2P(Q) | 1 | 13.2 |
| 2P(Q) | 1.5 | 14.5 |
| 2P(Q) | 2.5 | 15.8 |
| 5P | 0.5 | 20.1 |
| 5P | 0.75 | 21.2 |
| 5P | 1 | 21 |
| 5P | 1.5 | 23.7 |
| 5P | 2.5 | 26.9 |
| 10P | 0.5 | 27.6 |
| 10P | 0.75 | 29.5 |
| 10P | 1 | 29.1 |
| 10P | 1.5 | 33.5 |
| 10P | 2.5 | 36.4 |
| 15P | 0.5 | 30.9 |
| 15P | 0.75 | 34 |
| 15P | 1 | 33.4 |
| 15P | 1.5 | 37.6 |
| 15P | 2.5 | 41.2 |
| 20P | 0.5 | 35 |
| 20P | 0.75 | 37.3 |
| 20P | 1 | 36.8 |
| 20P | 1.5 | 41.8 |
| 20P | 2.5 | 45.4 |
| NO. OF PAIRS | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL OVERALL DIAMETER mm |
|---|---|---|
| 2P | 0.5 | 16 |
| 2P | 0.75 | 17.2 |
| 2P | 1 | 17 |
| 2P | 1.5 | 18.7 |
| 2P | 2.5 | 20.9 |
| 5P | 0.5 | 20.4 |
| 5P | 0.75 | 21.5 |
| 5P | 1 | 21.3 |
| 5P | 1.5 | 24 |
| 5P | 2.5 | 27.2 |
| 10P | 0.5 | 28.1 |
| 10P | 0.75 | 30 |
| 10P | 1 | 29.6 |
| 10P | 1.5 | 34.2 |
| 10P | 2.5 | 36.9 |
| 15P | 0.5 | 31.5 |
| 15P | 0.75 | 34.6 |
| 15P | 1 | 34.2 |
| 15P | 1.5 | 38.2 |
| 15P | 2.5 | 41.8 |
| 20P | 0.5 | 35.7 |
| 20P | 0.75 | 38 |
| 20P | 1 | 37.5 |
| 20P | 1.5 | 42.5 |
| 20P | 2.5 | 46.1 |
| 30P | 0.5 | 40.9 |
| 30P | 0.75 | 43.6 |
| 30P | 1 | 43 |
| 30P | 1.5 | 49.5 |
| 30P | 2.5 | 54 |
