BS5308 / PAS5308 Part 2 Type 1 & 2 Cable

BS5308 / PAS5308 Part 2 Type 1 & 2 Cable Description

Both cables are used for communication and instrumentation signal transmission in industrial and commercial environments. Type 1 cables are designed for fixed applications and are usually used indoors. Type 2 cables use steel wire armor (SWA) and are commonly used in the petrochemical and chemical industries.

As with instrumentation cables, all core configurations and cable sizes are shielded and shielded with aluminum polyester tape (Al/PET) and either core shield or individual core shield (CAM or ICAM / IAM / PiMF). Double shield tape and metal foil on the wire pairs provide additional electromagnetic protection.

Although the original BS 5308 standard has been superseded by PAS 5308, it is still widely referenced.

Type 2 Cable

BS5308 / PAS5308 Part 2 Type 1 & 2 Cable Construction

	BS5308 Part 2 Type 1 CAM PVC Cable	BS5308 Part 2 Type 1 ICAM PVC Cable	BS5308 Part 2 Type 2 CAM SWA PVC Cable	BS5308 Part 2 Type 2 ICAM SWA PVC Cable
VOLTAGE	300/500V
CONDUCTOR	Class 1 Solid Copper Class 2 Stranded Copper Class 5 Flexible Stranded Copper
INSULATION	PVC (Polyvinyl Chloride)
INDIVIDUAL SCREEN	-	Al/PET (Aluminium/Polyester Tape)	-	Al/PET (Aluminium/Polyester Tape)
COLLECTIVE SCREEN	Al/PET (Aluminium/Polyester Tape)
DRAIN WIRE	Tinned Copper
ARMOUR	-		SWA (Galvanised Steel Wire)
OUTER SHEATH	PVC (Polyvinyl Chloride)
BEDDING	-		PVC (Polyvinyl Chloride)

BS5308 / PAS5308 Part 2 Type 1 & 2 Cable Characteristics

Voltage Rating (Uo/U)
300/500V
Temperature Rating
Fixed: -40ºC to +80ºC
Flexed: 0ºC to +50ºC
Minimum Bending Radius
Fixed: 6 x overall diameter
Fixed: 12 x overall diameter (CAM / ICAM SWA PVC Cable)

BS5308 Part 2 Type 1 CAM PVC Cable
BS5308 Part 2 Type 1 ICAM PVC Cable
BS5308 Part 2 Type 2 CAM SWA PVC Cable
BS5308 Part 2 Type 2 ICAM SWA PVC Cable

NO. OF PAIRS/TRIPLE	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm
1P	0.5	7
1P	0.75	7.4
1P	1	7.4
1P	1.5	8.3
1P	2.5	9.1
1T	0.5	7.3
1T	0.75	7.7
1T	1	7.7
1T	1.5	8.9
1T	2.5	9.7
2P(Q)	0.5	7.9
2P(Q)	0.75	8.4
2P(Q)	1	8.4
2P(Q)	1.5	9.7
2P(Q)	2.5	10.7
5P	0.5	13.1
5P	0.75	13.8
5P	1	14.2
5P	1.5	16.4
5P	2.5	18.2
10P	0.5	17.2
10P	0.75	18.9
10P	1	18.4
10P	1.5	21.6
10P	2.5	25.1
15P	0.5	19.8
15P	0.75	21.9
15P	1	21.3
15P	1.5	25.4
15P	2.5	29.2
20P	0.5	22.3
20P	0.75	24.6
20P	1	24.4
20P	1.5	28.5
20P	2.5	39.8

NO. OF PAIRS/TRIPLE	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm
2P	0.5	10.7
2P	0.75	11.4
2P	1	11.3
2P	1.5	13.1
2P	2.5	14.5
3P	0.5	12.1
3P	0.75	12.8
3P	1	13.4
3P	1.5	14.5
3P	2.5	15.9
5P	0.5	13.6
5P	0.75	14.5
5P	1	14.5
5P	1.5	16.8
5P	2.5	18.9
10P	0.5	19
10P	0.75	20.4
10P	1	20.4
10P	1.5	23.9
10P	2.5	26.9
15P	0.5	21.9
15P	0.75	23.8
15P	1	23.7
15P	1.5	27.6
15P	2.5	31.1
20P	0.5	24.6
20P	0.75	26.8
20P	1	26.7
20P	1.5	31.1
20P	2.5	35.3
30P	0.5	29.2
30P	0.75	31.5
30P	1	31.4
30P	1.5	36.8
30P	2.5	41.8

NO. OF PAIRS/TRIPLE	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm
1P	0.5	11.4
1P	0.75	11.8
1P	1	11.8
1P	1.5	12.9
1P	2.5	13.7
1T	0.5	11.7
1T	0.75	12.1
1T	1	12.3
1T	1.5	13.5
1T	2.5	17.3
2P(Q)	0.5	12.3
2P (Q)	0.75	13
2P (Q)	1	13
2P (Q)	1.5	14.3
2P (Q)	2.5	15.3
5P	0.5	17.9
5P	0.75	19.3
5P	1	19.7
5P	1.5	22.1
5P	2.5	24.1
10P	0.5	22.9
10P	0.75	25.5
10P	1	24.3
10P	1.5	28.4
10P	2.5	32.1
15P	0.5	26.4
15P	0.75	28.7
15P	1	28.1
15P	1.5	32.2
15P	2.5	36.4
20P	0.5	29.1
20P	0.75	31.6
20P	1	31.2
20P	1.5	35.7
20P	2.5	41

NO. OF PAIRS	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm
2P	0.5	15.3
2P	0.75	16
2P	1	15.9
2P	1.5	18.6
2P	2.5	20
3P	0.5	15.9
3P	0.75	16.6
3P	1	16.8
3P	1.5	20.1
3P	2.5	23.5
5P	0.5	19.1
5P	0.75	20
5P	1	20
5P	1.5	22.5
5P	2.5	25.5
10P	0.5	25.6
10P	0.75	27
10P	1	27
10P	1.5	30.7
10P	2.5	33.9
15P	0.5	28.7
15P	0.75	30.6
15P	1	30.5
15P	1.5	34.6
15P	2.5	39.3
20P	0.5	31.6
20P	0.75	33.8
20P	1	33.7
20P	1.5	39.3
20P	2.5	43.7
30P	0.5	36.4
30P	0.75	39.7
30P	1	39.6
30P	1.5	45.2
30P	2.5	51.6
