SPEN Cable Description
SPEN cables feature aluminum conductors, cross-linked polyethylene (XLPE) insulation, and a medium-density polyethylene (MDPE) outer sheath. They are available in voltages of 6.35/11kV and 19/33kV. They are suitable for grid, underground, outdoor, and duct installation.
SPEN Cable Construction
| SPEN 11kV Single Core Cable | SPEN 11kV Three Core Cable | SPEN 33kV Single Core Cable | |
|---|---|---|---|
| Conductor | Class 1 Solid Aluminium Conductor | Class 2 Stranded Aluminium | |
| Insulation | XLPE (Cross-Linked Polyethylene) | ||
| Screen | Copper Wires and Equalising Copper Tape | ||
| Separator | Binding tape | ||
| Sheath | MDPE (Medium-Density Polyethylene) | ||
SPEN Cable Characteristics
| SPEN 11kV Single Core Cable | SPEN 11kV Three Core Cable | SPEN 33kV Single Core Cable | |
|---|---|---|---|
| Voltage Rating | 6.35/11 (12)kV | 19/33 (36)kV | |
| Temperature Rating | 0°C to +90°C | ||
- SPEN 11kV Single Core Cable
- SPEN 11kV Three Core Cable
- SPEN 33kV Single Core Cable
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL AREA OF METALLIC SCREEN mm² | NOMINAL OVERALL DIAMETER OF CABLE (OR TRIPLEX GROUP IF APPLICABLE) mm² | NOMINAL WEIGHT OF CABLE (OR TRIPLEX GROUP IF APPLICABLE) kg | MINIMUM BENDING RADIUS mm | MAXIMUM PULLING TENSION N |
|---|---|---|---|---|---|---|
| 1 | 95 | 35 | 27 | 980 | 510 | 2850 |
| 1 | 185 | 35 | 32 | 1320 | 605 | 5550 |
| 1 | 300 | 35 | 37 | 1750 | 700 | 9000 |
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL AREA OF METALLIC SCREEN mm² | NOMINAL OVERALL DIAMETER OF CABLE (OR TRIPLEX GROUP IF APPLICABLE) mm² | NOMINAL WEIGHT OF CABLE (OR TRIPLEX GROUP IF APPLICABLE) kg | MINIMUM BENDING RADIUS mm | MAXIMUM PULLING TENSION N |
|---|---|---|---|---|---|---|
| 3 | 95 | 70 | 55 | 3250 | 1050 | 8550 |
| 3 | 185 | 95 | 65 | 4880 | 1250 | 16650 |
| 3 | 300 | 95 | 75 | 6580 | 1440 | 27000 |
| NO. OF CORES | NOMINAL CROSS SECTIONAL AREA mm² | NOMINAL AREA OF METALLIC SCREEN mm² | NOMINAL OVERALL DIAMETER OF CABLE (OR TRIPLEX GROUP IF APPLICABLE) mm² | NOMINAL WEIGHT OF CABLE (OR TRIPLEX GROUP IF APPLICABLE) kg | MINIMUM BENDING RADIUS mm | MAXIMUM PULLING TENSION N |
|---|---|---|---|---|---|---|
| 1 | 150 | 50 | 43 | 1900 | 825 | 4500 |
| 1 | 240 | 50 | 46 | 2290 | 880 | 7200 |
| 1 | 400 | 50 | 52 | 2900 | 1000 | 12000 |
