H1XDV-AS Cable

H1XDV-AS Cable Description

H1XDV-AS cable consists of three aluminum phase conductors (round or fan-shaped) and a smaller Category 1 solid aluminum neutral conductor. It features a UV-resistant PVC outer sheath and XLPE insulation, with steel tape armor providing additional mechanical protection. This cable conforms to the French NF C33-210 standard.

H1XDV-AS Cable Construction

Conductor
RE: Class 1 round solid aluminium
RM: Class 2 round stranded aluminium
SM: Class 2 sector shaped stranded aluminium
Insulation
XLPE (Cross-Linked Polyethylene)
Armour
Steel Tape
Outer Sheath
PVC (Polyvinyl Chloride)

H1XDV-AS Cable Characteristics

Voltage Rating
0.6/1kV
Temperature Rating
Minimum laying temperature: -5ºC
Operating temperature: -15ºC to +60ºC
Maximum Conductor temperature: +90ºC
Short Circuit Temperature
250°C
Minimum Bending Radius
Single core: 15 x overall diameter
Multi-core: 12 x overall diameter

H1XDV-AS Cable Specification

NO. OF CORES	NOMINAL CROSS SECTIONAL AREA mm²	NOMINAL OVERALL DIAMETER mm	NOMINAL WEIGHT kg/km
3	95+50	33.9	1650
3	150+70	41.4	2300
3	240+95	51.4	3450
